AD Dogbone M830 inlays from Avery Dennison are designed for global supply chain, industrial, RTI, and sports timing applications. They excel through superior performance in demanding environments and on difficult-to-tag materials, due to their good tolerance against the detuning effect of high dielectric materials.
AD Dogbone M830 inlays feature 128-bit of EPC memory and a 96-bit unique factory locked TID number. A 48-bit unique serial number is factory-encoded into the TID. The improved readability of the new IC offers reliable reading of small tags at high volume and speed which supports the global IoT deployments, according to the company’s press release.
Dogbone M830 inlays have a size of 97 x 27 mm, which is optimized for 100 mm / 3.94 inch wide converted labels, and are available in wet +, and label delivery formats.
Like all RFID products from Avery Dennison, AD Dogbone M830 inlays are manufactured according to the industry’s highest quality standards, as confirmed by the RFID Lab at Auburn University – the inspection body awarded Avery Dennison its first comprehensive and significant ARC accreditation for quality.
High performance condensed to the max
AD Squarewave M830 inlays and tags are designed for industrial and supply-chain applications, offering excellent performance not only on low detuning materials such ascardboard and plastic, but also on materials with high dielectric effect, according to the company’s press release. With relatively narrow width, this product has a flat global performance over the whole UHF band on a variety of materials.
AD Squarewave M830 inlays and tags are a size-optimized 97 mm / 3.82 inch form factor,making them suitable for use with a wide range of supply chain labels, and are available indry, wet + and label delivery formats.
The AD Squarewave M830 feature 128-bit of EPC memory and a 96-bit unique factorylocked TID number. A 48-bit unique serial number is factory-encoded into the TID. The improved readability of the new IC offers reliable reading of small tags at high volume and speed which supports the global IoT deployments.
Like all RFID products from Avery Dennison, AD Squarewave M830 inlays are manufactured according to the industry’s highest quality standards, as confirmed by the RFID Lab at Auburn University – the inspection body awarded Avery Dennison its first comprehensive and significant ARC accreditation for quality.
Tech details overview AD-Dogbone-M830-07-24-EN-DS
Frequency Band – UHF 860 – 960 MHz
Chip Attachment Technology – Direct Chip Attach
Chip – Impinj M830
Antenna Dimensions – 94 x 24 mm / 3.70 x 0.95 in
International Standard ISO 18000-63 EPC class 1 Gen 2
Industry Segments – Logistics Automotive Sports and events
Applications – Inventory and Logistics Supply Chain Management Sports Timing
RoHS – EU Directive 2011/65/EC and Directive (EU) 2015/863
REACH – Regulation (EC) No. 1907/2006
Tech details overview AD Squarewave M830
Frequency Band – UHF 860 – 960 MHz
Chip – Impinj M830
Antenna Dimensions – 93 x 11 mm / 3.66 x 0.43 in
International Standard – ISO/IEC 18000-63, EPC Gen2 V2
Primary Industry Segment – Industry
Secondary Industry Segments – Logistics – Automotive
Applications – Supply Chain Management – Inventory and Logistics – Home Essentials
RoHS – EU Directive 2011/65/EC and Directive (EU) 2015/863
REACH – Regulation (EC) No 1907/2006
